Latest on this site:

Corrections to analysis of bell harmonics at Wavendon and Great Linford - June 2022


BellDocumented NoteDocumented Note SourceRecorded NoteRecorded WeightEstimated WeightDiameterFounderMP3
5GDoveG12 - 0 - 011 - 0 - 1140Watts in 1591

Inscriptions:

#####################
@ABCDEFGHIKLMNOPQABCDEFGHIKLMNOPQRS 1591


Trapezoids

How does the shape of this bell compare to others in the ring?


Here, the shape of all the bells are compared by reducing their size so they all have the same radius at the soundbow.
Then we can see if the founder made bells taller, wider or the same shape as different sized bells were created.

Tonal Analysis
Is this bell in tune with itself?
ToneFrequency (Hz)Tuning
Hum20064
Prime39020
Tierce47043
Quint572-17
Nominal7710
Upper Third97113
Upper Quint1136-31
Upper Octave155413

This shows each harmonic relative to what it should be relative to the Nominal
taking Simpson Tuning as an ideal.
A positive figure shows that the harmonic is sharp, a negative figure shows that it is flat. There are 100 cents between notes on the scale.
Nominal:771Hz
Flat of G by 13 cents
