Corrections to analysis of bell harmonics at Wavendon and Great Linford - June 2022


BellDocumented NoteDocumented Note SourceRecorded NoteRecorded WeightEstimated WeightDiameterFounderMP3
6  E3 - 1 - 123 - 2 - -125½Taylor in 1992

Inscriptions:

A gift of the Oxford Diocesan Guild of Church Bell Ringers to commemorate the 450th. Anniversary of the Diocese


Trapezoids

How does the shape of this bell compare to others in the ring?


Here, the shape of all the bells are compared by reducing their size so they all have the same radius at the soundbow.
Then we can see if the founder made bells taller, wider or the same shape as different sized bells were created.

Tonal Analysis
Is this bell in tune with itself?
ToneFrequency (Hz)Tuning
Hum328-3
Prime6583
Tierce78610
Quint967-31
Nominal13140
Upper Third169656
Upper Quint1958-12
Upper Octave268437

This shows each harmonic relative to what it should be relative to the Nominal
taking Simpson Tuning as an ideal.
A positive figure shows that the harmonic is sharp, a negative figure shows that it is flat. There are 100 cents between notes on the scale.
Nominal:1314Hz
Flat of E by 5 cents
