Corrections to analysis of bell harmonics at Wavendon and Great Linford - June 2022


BellDocumented NoteDocumented Note SourceRecorded NoteRecorded WeightEstimated WeightDiameterFounderMP3
1  E - - 3 - 3 - 526Taylor in 1901

Inscriptions:



Trapezoids

How does the shape of this bell compare to others in the ring?


Here, the shape of all the bells are compared by reducing their size so they all have the same radius at the soundbow.
Then we can see if the founder made bells taller, wider or the same shape as different sized bells were created.

Photos
 Removal of the bells
Tonal Analysis
Is this bell in tune with itself?
ToneFrequency (Hz)Tuning
Hum3275
Prime650-5
Tierce775-1
Quint976-2
Nominal13040
Upper Third169871
Upper Quint1947-8
Upper Octave266638

This shows each harmonic relative to what it should be relative to the Nominal
taking Simpson Tuning as an ideal.
A positive figure shows that the harmonic is sharp, a negative figure shows that it is flat. There are 100 cents between notes on the scale.
Nominal:1304Hz
Flat of E by 15 cents
