Latest on this site:

Corrections to analysis of bell harmonics at Wavendon and Great Linford - June 2022


BellDocumented NoteDocumented Note SourceRecorded NoteRecorded WeightEstimated WeightDiameterFounderMP3
1  D - - 5 - 0 - 1629½Pack & Chapman in 1773

Inscriptions:

THO.S ROGERS & JN.O STUBBS CHURCHWARDENS + PACK & CHAPMAN OF LONDON FECIT 1773


Trapezoids

How does the shape of this bell compare to others in the ring?


Here, the shape of all the bells are compared by reducing their size so they all have the same radius at the soundbow.
Then we can see if the founder made bells taller, wider or the same shape as different sized bells were created.

Tonal Analysis
Is this bell in tune with itself?
ToneFrequency (Hz)Tuning
Hum312121
Prime566-48
Tierce70429
Quint926104
Nominal11640
Upper Third149648
Upper Quint1724-22
Upper Octave239952

This shows each harmonic relative to what it should be relative to the Nominal
taking Simpson Tuning as an ideal.
A positive figure shows that the harmonic is sharp, a negative figure shows that it is flat. There are 100 cents between notes on the scale.
Nominal:1164Hz
Flat of D by 11 cents
